Rotel Michi X5 Series 2 Stereo Integrated Amplifier
The Michi X5 Series 2 Integrated Amplifier is music reproduction reimagined. Thanks to a meticulous balance of innovation and critical audio engineering applied...
See descriptionThe Michi X5 Series 2 Integrated Amplifier is music reproduction reimagined. Thanks to a meticulous balance of innovation and critical audio engineering applied to every circuit, signal path, and electronic component, the Michi X5 Series 2 is capable of delivering a breathtaking 600 Watts of Class AB output power into 4 ohms or 350 watts into 8 ohms under even the most demanding conditions.
Exclusive at: O'ConnorOsborne Park
$11,999.00
AUD Inc. GST
BEST PRICE GUARANTEE
SPEAK TO OUR TEAM • TEXT US
The Michi X5 Series 2 Integrated Amplifier is music reproduction reimagined. Thanks to a meticulous balance of innovation and critical audio engineering applied to every circuit, signal path, and electronic component, the Michi X5 Series 2 is capable of delivering a breathtaking 600 Watts of Class AB output power into 4 ohms or 350 watts into 8 ohms under even the most demanding conditions.
Connect all your favourite music sources including Analogue RCA and XLR Balanced, Moving Magnet or Moving Coil Phono, aptXTM HD Wireless Bluetooth, Coaxial and Optical. The PC-input supports PCM (32-bit 384kHz) and Quad DSD (11.2MHz) with full MQA hardware decoding up to 24-bit 384kHz.
An ESS SABRE ES9028PRO 8-Channel Digital to Analogue converter is configured for stereo decoding, dedicating 4 channels each to the left and right audio signals rendering music with exceptionally accurate timing and an immersive soundstage which reveals the finest of details.
The Michi X5 Series 2 is powered by dual oversized in-house manufactured, shielded, low noise toroidal transformers feeding a bank of 4 parallel-aligned 22,000uF high-efficiency storage reservoir capacitors. Custom power supplies isolate drive current to critical analog and digital circuits delivering an ultra- quiet noise floor with exceptional control of deep bass energy while maintaining finesse and clarity of the midrange and high frequencies.
The high-resolution graphic display is configurable to show a Graphic EQ or Peak Power Meter and ensures easy setup and configuration. Custom front panel controls and the elegant Michi-series IR remote assures seamless operation from the comfort of your listening chair.
Dual Platinum-plated custom Michi speaker binding posts support traditional and bi-wire installations. A full size 1⁄4” (6.35mm) front panel headphone connection is available for private listening sessions.
RS232 and Ethernet ports provide compatibility with all popular control systems.
Amplification
Amplifier Class AB
Continuous Power Output 600 W/Ch (4 Ω), 350 W/Ch (8 Ω)
Total Harmonic Distortion (THD) <0.009%
Frequency Response Line Level Inputs: 10 Hz – 100 kHz (+0 dB, -0.6 dB), Digital Inputs: 20 Hz – 20 kHz (0 ± 0.4 dB), Phono Input: 20 Hz – 20 kHz (+0 dB, +0.2 dB)
S/N Ratio (IHF “A” Weighted) Line Level Inputs: 102 dB, Digital Inputs: 102 dB, Phono Input: 80 dB
Intermodulation Distortion (60 Hz:7 kHz, 4:1) <0.03% Damping Factor (20 Hz – 20 kHz, 8 Ω) 350 Channel Separation >65 dB
Input Sensitivity Line Level Inputs (RCA): 380 mV, Line Level Inputs (XLR): 580 mV, Phono Input (MM): 5.7 mV, Phono Input (MC): 570 uV
Input Impedance Line Level Inputs (RCA): 100 kΩ, Line Level Inputs (XLR): 100 kΩ, Digital Inputs: 75 Ω, Phono Input (MM): 47 kΩ, Phono Input (MC): 100 Ω
Input Overload Line Level Inputs (RCA): 12.5 V, Line Level Inputs (XLR): 12.5 V, Phono Input (MM): 197 mV, Phono Input (MC): 19 mV
Preout Level 1 V
Output Impedance 470 Ω
Tone Controls ±10 dB at 100 Hz / 10 kHz
Coax/Optical Digital Input Signals SPDIF LPCM (Up to 24-bit/192 kHz)
PC-USB USB Audio Class 1: Up to 24-Bit/96 kHz, USB Audio Class 2: Up to 24-Bit/384 kHz (Driver Installation Required), DSD and DoP Support, MQA and MQA Studio Support, Roon Tested
Dimensions & Weight
Dimensions (W x H x D) 485 x 195 x 452 mm (19″ x 7 5/8″ x 17 3/4″)
Front Panel Height 177 mm (7″)
Power Requirements 230 V, 50 Hz
Power Consumption 850 W
Standby Power Consumption <0.5 W
Net Weight 43.8 kg (96.56 lb)
BTU Rating 2194 BTU/h
