Australian Monitor ZONEMIX4 4 Zone Mixer and Paging System

ZONEMIX4

The ZONEMIX4 provides a 4 zone mixing and paging solution featuring USB, Ethernet and RS232 connectivity. Optional wall panel accessories include 3 controller models, a Bluetooth receiver, and a mic/line level input. The ZMPS paging station can also be included, with each ZONEMIX unit supporting up to 16 stations. A PC application allows for setup and control of the ZONEMIX and customisation of the wall panels and paging stations.

FEATURES

Input/Output Mixing:- 2 mic/line and 4 line inputs to 4 zone outputs

miniDSP

Builtin EVAC, Intruder, Bell and Chime tones

Tone can be customised via SD Card (not supplied)

Custom messages can be stored on the SD Card and triggered via the scheduler, contact closure, ZMPS paging station or wall panels

Multi level priority

Scheduler to trigger global, or zone presets, contract closure outputs, tones and pre-recorded messages.

4 contact closure inputs and outputs

Support for up to 16 ZMPS paging stations

Supports one local audio input per output zone
