Blustream MX44VW 4×4 4K Seamless Switching HDMI/VGA Matrix

The Blustream  MX44VW 4K HDMI/VGA matrix is a multi-purpose high-speed video processing system. The MX44VW can be configured for 3 different output modes....

See description

The Blustream  MX44VW 4K HDMI/VGA matrix is a multi-purpose high-speed video processing system. The MX44VW can be configured for 3 different output modes. The MX44VW can perform as a 4×4 seamless matrix switcher, as a 2×2, 4×1 or 1×4 video wall solution, and as a quad multi-view presentation system.

Inputs can be assigned as either HDMI or VGA with associated L/R analogue audio with control of the switcher via the front-panel push buttons, Blustream Matrix App, IR remote control, RS-232 interface and TCP/IP.

$3,599.00

AUD Inc. GST

BEST PRICE GUARANTEE

SPEAK TO OUR TEAM • TEXT US

Free Shipping

Australia wide on orders over $100

FREE SHIPPING Australia wide on orders over $100
In Stock

or 6 payments of $599.83 with zip

Own it now, pay later Learn More

Category ,
Tags , , ,

Key Features

Features 3 operational modes:
– 4×4 Seamless Switching Matrix (HDMI or VGA inputs)
– Video Wall (2×2, 4×1 or 1×4 configuration)
– Multi-Viewer mode with preset layouts

Features 4x video inputs that can be configured as HDMI video or VGA video with associated L/R analogue audio

Instantaneous seamless video switching (Matrix and Video Wall modes)

Video inputs support industry standard video resolutions including VGA-WUXGA (up to 1920×1200 @60Hz) and 480i-4K (3840×2160 @30Hz 4:4:4, 4096×2160 @24Hz 4:4:4)

HDMI output resolution fixed to 1080p @60Hz

Supports HDMI 2ch PCM audio only

Discreet IR routing

Supplied with Blustream IR receivers and emitters

Control via front panel, IR, RS-232, TCP/IP and the Blustream Matrix App

3rd party control drivers available for all major home control brands

Advanced EDID management

HDCP1.4 compliant



Video Input Connectors: 4x HDMI Type A, 19-pin, female, locking & 4x VGA Video Output Connectors: 4x HDMI Type A, 19-pin, female, locking Audio Input Connectors: 4x Analogue audio 3.5mm stereo Jack RS-232 serial port: DB-9, female TCP/IP Control: RJ45, female IR Input ports: 5x 3.5mm stereo jack IR Output ports: 4x 3.5mm mono jack Casing Dimensions (W x H x D): 440mm x 45mm x 180mm Dimensions including connections (W x H x D): 440mm x 44mm x 187mm Shipping Weight: 4.0kg Operating Temperature: 32°F to 104°F (0°C to 40°C) Storage Temperature: -4°F to 140°F (-20°C to 60°C) Power Supply: 12V/3A DC

Box Contents

1 x MX44VW matrix 1 x 12V/3A DC power supply 1 x IR remote control 4 x IR emitters 5 x IR receivers 1 x Rack mounting kit 1 x User manual
